Här kommer en sammanfattning av de Cubesats som kom upp under februari 2014:
ISS deployment från den 28/2:
LituanicaSAT-1
• FM Transponder Uplink 145.950 MHz Downlink 435.180 MHz
• AX25 Uplink 145.850 MHz AX25 Downlink 437.550 MHz
• CW Beacon 437.275 MHz
Facebook https://www.facebook.com/Lituanicasat1
LitSat-1
• SSB Transponder Uplink 435.180 MHz Downlink 145.950 MHz
• AX25 Uplink 437.550 MHz Downlink 145.850 MHz
Facebook https://www.facebook.com/palydovas
ArduSat-2
• 9k6 MSK CCSDS data format downlink 437.? MHz
http://www.kickstarter.com/projects/575960623/ardusat-your-arduino-experiment-in-space
UAPSAT
• AX.25 Packet Radio uplink 145.980 MHz downlink 437.385 MHz
http://www.uapsat.info/ Twitter https://twitter.com/uapsat Facebook https://www.facebook.com/uapsat
Japanska Cubesats som kom upp den 27/2:
Downlink frequencies in MHz all +/- 10 kHz Doppler shift:
STARS-II (Mother) – 437.405 FM AX.25 1200 bps, 437.245 CW
STARS-II (Daughter) – 437.425 FM AX.25 1200 bps, 437.255 CW
ShindaiSat – 437.525 FM AX.25 1200 bps, 437.305 CW (LED beacon)
TeikyoSat-3 – 437.450 FM AX.25 1200 bps, 437.450 CW (Slime Mold from Space)
OPUSAT – 437.150 FM AX.25 1200 bps, GMSK 9600 bps
ARTSAT1-INVADER – 437.200 FM Digitalker and AX.25 1200 bps, 437.325 CW
ITF-1 – 437.525 FM Morse code
Stort tack till AMSAT-UK för förstklassig info! Thanks to AMSAT-UK for top-of-the-line info about the new Cubesats.
